Flamefast GASGUARD - EXTERNAL DEVICE WIRING; AIR DP SWITCH WIRING; REMOTE STOP AND FIRE ALARM CONNECTIONS; CO2 SENSOR WIRING

FLAMEFAST RESERVE THE RIGHT TO CHANGE PRODUCT SPECIFICATION WITHOUT PRIOR NOTICE GG_V3.00_OM_022024
AIRDPS/RSTOP/FIRE
TR-CO2TL
CO2M
L N
VFC
CO2
VFC IN
1
DIP Switches 3 & 4 must be
set to ON when interlocking
into a Gas Safety System
ON
Programming
100-240V AC POWER
(WIRED IN PARALLEL
WITH MAINS IN)
2
3
4
CO2M
GASGUARD or SERVICEGUARD
16 17
SCR B A
RELAY
THERM
RH
(A03)
T
(A02)
CO2
(A01)
0V 24V
0-10V OUT
AC/DC
CO2
VFC IN
24V
+ -
V
GG
Program Select Jumper
must be set to GG
TR-CO2TL
12 13 16 17
GASGUARD or SERVICEGUARD
RSTOP
FIRE ALARM TO PROVIDE A
NORMALLY CLOSED VOLT
FREE CONTACT INTERFACE
INTAKE
FAN
EXTRACT
FAN
REMOTE
STOP
FIRE
ALARM
10 11987654
2
3
INTAKE AIR DP SWITCH
2
3
EXTRACT AIR DP SWITCH
2
3
RSTOP-C
WHEN USING MULTIPLE
AIR DP SWITCHES
THESE MUST BE WIRED
IN SERIES
GASGUARD or SERVICEGUARD
EXTRACT AIR DP SWITCH
1
4
