Manual external FLARM™ / PowerFLARM™ Display V3+Mm
External FLARM™/ PowrFLARM™ Display
V3+Mm
with Software-version 3.7
Page 9
Configuration
The display V3+M allows adjustments of diverse parameters as basic settings; these adjusted parameters
then act as standard settings.
To reach the setup mode the display must be disconnected from power (remove connector) and then
reconnected with Mode button pressed momentarily and this will then allow you to configure the display as
in the table below. A short confirmation beep as well as flashing decimal points on the distance indicator will
appear until leaving this mode.
-> The status-LED’s indicate the selected parameters along with the LED’s of the compass rose showing
corresponding values.
-> On the distance indicator the direct numerical values are indicated: 10
th
= parameter number, 1
st
= value
Operating in configuration mode:
o A short press of the Mode button changes (increases) the value of the chosen parameter. All changes
are saved and immediately valid.
o In order to change the next parameter the button must be pressed for a period of 1-2 s.
o To leave the setup mode and/or an activation of new adjustments the button must be pressed longer
than 3 s or FLARM, including the display, must be restarted (cut power supply and power up again).
Parameter No. 1.- 2.- 3.- 4.- 5.- 6.-
Parameter brightness indicator
parallel
operation
FLARM
TM
mainframe
interface
unit of
measurement
compatibility
mode
Status LED RX TX GPS Power RX + TX TX + GPS
Value 1 – 15° strongly dimmed
display PIC
LED: on
signal: on
4800 Baud KM indication
OFF
direction 1 LED
Value 2 – 45° dimmed display PAX
LED: off
signal: off
9600 Baud NM indication
ON
direction 1..3 LED
Value 3 – 75° normal
LED: off
signal: on
19 200 Baud
Value 4 – 105° bright
LED: on
signal: off
28 800 Baud
Value 5 – 135° very bright (max) 38 400 Baud
Value 6 – 165°
sensor adjustment
- dimmed -
57 600 Baud
Value 7 – 195°
sensor adjustment
- normal -
Value 8 – 225°
sensor adjustment
- bright -
bold print/underlined = standard settings
Tip: A parallel operation with devices/displays from other companies on the same interface requires the
transfer speed to be set to 4,800 Baud as a standard setting.We strongly recommend not using the
display V3+M in combination with other brands of devices on the same interface – a parallel operation
with two V3+/V3+/V3+M displays (e.g. two-seater) was specifically designed during development and
operate optimally together at 4,800 Baud, with the configuration PIC/PAX (parameter 2).
Operating with a parallel connection to the display with other products cannot be guaranteed and related
service support will be denied.
