FlashLogic FLRSGM10 - Page 7

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 2 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
CHEVY
Traverse with Auto
Up/Down Windows
09-17
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
GMC
Acadia 07-16
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Acadia with Auto
Up/Down Windows
07-16
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Acadia limited 17
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Savana 08-17
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Sierra 07-13
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Sierra Premium
Package
07-13
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Yukon / XL /
Denali / Hybrid
07-14
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
HUMMER
H2 08-09
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
PONTIAC
G8 08-09
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Torrent 07-09
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
SATURN
Outlook 07-10
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Outlook with Auto
Up/Down Windows
07-10
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
SUZUKI
XL7 07-09
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
