FlashLogic FLRSGM10 - Wire Chart

U.S. Patent No. 8,856,780
TYPE 1 - WIRE CHART - 1 OF 2
MAKE MODEL YEAR WIRE DESCRIPTION CONNECTOR NAME CONNECTOR COLOR CONNECTOR TYPE POSITION WIRE COLOR POLARITY MODULE LOCATION COMPONENT LOCATOR
BUICK
Enclave 08-17
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Lucerne 06-11
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue/Tan (-) At headlight switch ~
CADILLAC
CTS 08-14
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
DTS 06-11
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Escalade / ESV /
Hybrid
07-14
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Escalade EXT 07-13
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
CHEVROLET
Avalanche 07-13
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Caprice 11-13
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Equinox 07-09
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Express 08-17
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Impala 06-13
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Impala limited 13-16
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Monte Carlo 06-09
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
Silverado / Hybrid 07-13
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Silverado / Hybrid
Premium Package
07-13
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Suburban 07-14
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Tahoe / Hybrid 07-14
Driver Door Pin ~ ~ ~ ~ ~ ~ Do not connect. Supported by data ~
Parking Light ~ ~ ~ ~ LtBlue (-) At headlight switch ~
Traverse 09-17
Driver Door Pin ~ ~ ~ ~ Gray/Black (-) Driver kick panel ~
Parking Light ~ ~ ~ ~ Brown/White (-) At headlight switch ~
