CONTENTS
Contents
Installation Instructions Page
Appliance Data 3
Section 1 1.1 Conditions of Installation. 4
1.2 Flue & Chimney Suitability 4
1.3 Fireplace/Surround Suitability 5
1.4 Shelf Position 5
1.5 Side Clearance 5
1.6 Closure Plate 5
1.7 Flue & Chimney inspection 5-6
1.8 Chimney Catchment space 6
1.8.1 Brick Built Chimney 6-7
1.8.2 Fitting to Pre-Fab. Twin Wall
Metal Flueboxes 7
1.8.3 Fitting to Pre-Cast Flue Installations 8
1.9 Hearth Fitting 8
1.10 Wall Mounting 8
1.11 Spillage Monitoring System 8
Section 2 2.1 Packing Check List 9
2.2 Installation of Fire 9-10
2.3 Gas Connection 11
2.4 Gas Soundness 12
.
Section 3 3.1 Completing the Assembly 12
3.2 Lighting the Appliance 12
3.3 Checking for Clearance of
Combustion Products 13
3.4 Final Checks 14
Section 4
Maintenance Instructions
4.1 General Access for Servicing 15
4.1.1 Removal of the Upper Canopy 15-16
4.2 Removal of the Burner Assembly 16-17
4.3 Removal of the Control Tap 18-19
4.4 Removal of the ODS 19
4.5 Removal / Replacement of the Radiants 19
