7) If you ever need to remove the tube, evenly press on
both sides of the grey ring surrounding the tube and
pull out as shown in Figure 10-A. i
Be sure to recut
the end of the tube each time you remove it to
ensure a proper seal when the tube is inserted
8) Finally, use ½” inner diameter (I.D.) tubing to connect
the drain barb fitting on the brine tank to a floor drain
as shown in Figure 10-B. Note that this is not neces-
sary as the 474 assembly is designed to prevent an
overflow from occuring, but it is a good precaution
FIGURE 10-A FIGURE 10-B
