Fleck 5800 SXT - C-UNIT CAPACITY Determination; BF-BRINE FILL Value

PAGE 5Help: 888-426-5001 QualityWaterForLess.com
5) C - UNIT CAPACITY: In the first column, identify the section containing your softener tank size and then within this
section, find the row pertaining to your H - Compensated Hardness level. Then look under the C - Capacity column
to find the most efficient program value to enter for your C - Unit Capacity and record it in the table on page 2.
Note that your unit capacity program value may actually be lower than the tank’s rated capacity. This is to
accommodate a lower salt dose for regeneration.
6) BF - BRINE FILL: In the first column, identify the section containing your softener tank size and then within this
section, find the row pertaining to your H - Compensated Hardness level. Then look under the BF - Brine Fill column
to find the most efficient program value to enter for your BF - Brine Fill and record it in the table on page 2.
7) Example: If you ordered a 64K grain capacity system and have 28 gpg compensated hardness, you would look under
the 64K, 2.0 cu ft section and then look under the 25+ gpg row for your particular programming values. Note that the
11x11” and the 15x17” brine tanks are too small for the amount of brine needed to regenerate a 64K grain capacity system
with 25+ gpg hardness. According to the table you would opt for an 18” diameter brine tank with a grid plus 6” legs
Tank Size
H
HARDNESS
C
CAPACITY
BF
BRINE FILL
lbs of Salt 11x11” G rid 15x17” Grid 18x33” Grid 18x40” Grid 24x41” Grid 24x50” Grid
24K
0.75 cu ft
8x44”
0 - 12 gpg 15K 6 Min 4.5 lbs Grid NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
12 - 25 gpg 20K 10 Min 7.5 lbs Grid Grid NO GRID NO GRID
25+ gpg 24K 14 Min 11.25 lbs Grid + 3” Legs Grid Grid Grid
32K
1.0 cu ft
9x48”
0 - 12 gpg 20K 8 Min 6 lbs Grid NO GRID NO GRID NO GRID
TOO
LARGE
TOO
LARGE
12 - 25 gpg 27K 14 Min 10 lbs Grid + 3” Legs Grid Grid Grid
25+ gpg 32K 20 Min 15 lbs Grid + 6” Legs Grid + 3” Legs Grid Grid
40K
1.25 cu ft
10x44”
0 - 12 gpg 25K 10 Min 7.5 lbs Grid Grid NO GRID NO GRID
TOO
LARGE
TOO
LARGE
12 - 25 gpg 34K 18 Min 12.5 lbs Grid + 3” Legs Grid Grid Grid
25+ gpg 40K 26 Min 18.75 lbs TOO SMALL Grid + 3” Legs Grid + 3” Legs Grid + 3” Legs
48K
1.5 cu ft
10x48”
0 - 12 gpg 30K 14 Min 9 lbs Grid + 3” Legs Grid Grid Grid
TOO
LARGE
TOO
LARGE
12 - 25 gpg 41K 20 Min 15 lbs Grid + 6” Legs Grid + 3” Legs Grid Grid
25+ gpg 48K 30 Min 22.5 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
64K
2.0 cu ft
12x52”
0 - 12 gpg 40K 16 Min 12 lbs Grid + 3” Legs Grid Grid Grid
Grid +
5” Legs
Grid +
5” Legs
12 - 25 gpg 54K 28 Min 20 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
25+ gpg 64K 40 Min 30 lbs TOO SMALL TOO SMALL Grid + 6” Legs Grid + 6” Legs
80K
2.5 cu ft
13x54”
0 - 12 gpg 50K 20 Min 15 lbs Grid + 6” Legs Grid + 3” Legs Grid Grid
Grid +
5” Legs
Grid +
5” Legs
12 - 25 gpg 68K 34 Min 25 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
25+ gpg 80K 50 Min 37.5 lbs TOO SMALL TOO SMALL TOO SMALL Grid + 6” Legs
96K
3.0 cu ft
14x65”
0 - 12 gpg 60K 24 Min 18 lbs TOO SMALL Grid + 3” Legs Grid + 3” Legs Grid + 3” Legs
Grid +
6” Legs
Grid +
6” Legs
12 - 25 gpg 81K 40 Min 30 lbs TOO SMALL TOO SMALL Grid + 6” Legs Grid + 6” Legs
25+ gpg 96K 60 Min 45 lbs TOO SMALL TOO SMALL TOO SMALL TOO SMALL
120K
4.0 cu ft
16x65”
0 - 12 gpg 80K 32 Min 24 lbs TOO SMALL Grid + 6” Legs Grid + 3” Legs Grid + 3” Legs
Grid +
8” Legs
Grid +
8” Legs
12 - 25 gpg 108K 54 Min 40 lbs TOO SMALL TOO SMALL TOO SMALL TOO SMALL
25+ gpg 120K 80 Min 60 lbs TOO SMALL TOO SMALL TOO SMALL TOO SMALL
