CSM 57 18-EC
Max. diameter mm
25
For threaded rod
Weight
according
to ”EPTA
Procedure
01/2003”
(without battery)
kg 2.48
Battery 18V
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
Weight of
battery
kg
AP 18.0/2.5
AP 18.0/5.0
AP 18.0/8.0
0.4
0.7
1.1
Working
Temperature
-10~40°C
Charging
Temperature
0~40℃
Storage
Temperature
- 20~50°C
Charger range
CA 12/18
CA 18.0-LD
CA 10.8/18.0
CA SP 2x 12/18
Overview (see figure A)
The numbering of the product features refers
to the illustration of the machine on the
graphics page.
1 Main handle
2 Trigger switch
3 Lock-off button
4 Upper guard
5 Transparent front guard
6 Base plate
7 Blade outer washer
8 Blade bolt
9 Lower guard
10 Lower guard lever
11 Chip box cover
12 Buckle
13 Transparent window
14 Shaft-lock button
15 Rafter hook
16 Depth-adjustment lever
17 Depth scale
18 Hex key
19 Auxiliary handle
20 Locking knob (with spring)
21 LED light
22 Track adaptor
23 Rip fence
24 Blade
Operating instructions
WARNING!
Remove the battery before carrying out any
work on the power tool.
Before switching on the power
tool
Unpack the power tool and accessories and
check that no parts are missing or damaged.
NOTE
The batteries are not fully charged on
delivery. Prior to initial operation, charge the
batteries fully. Refer to the charger operating
manual.
Tips for a long battery service life
CAUTION!
Never charge batteries at temperatures
below 0 °C or above 40 °C.
Do not charge batteries in environments
with high air humidity or ambient
temperature.
Do not cover batteries and the charger
during the charging process.
Pull out the charger mains plug at the end
of the charging process.
Battery and charger heat up during the
charging process. This is perfectly normal!
If batteries are not used for an extended
period of time, store them partially charged in
a cool place.
I
nserting/replacing the battery
(see figure B1-B2)
󰀲
Press the charged battery into the power
tool until it clicks into place (see figure B1).
󰀲
To remove, press the release button (1.) and
pull out the battery (2.) (see figure B2).
