Flex GE 5 User Manual

GE 5/GE 5 R/GSE 5 R
14
Maintenance and care
WARNING!
Before performing any work, pull out
the mains plug.
Cleaning
WARNING!
Do not use water or liquid detergents.
 Regularly blow out the housing interior
and motor with dry compressed air.
 Blow out the sanding head and gimbal
bearing with dry compressed air.
Replacing Velcro or backing pad
 Take hold of the sanding plate together
with the sanding head to prevent
the sanding plate from turning.
 Turn the screw in an anti-clockwise
direction and remove.
 Disassemble the sanding head.
 Replace parts.
 Assemble sanding head in reverse
sequence.
Replacing the brush ring
 Remove the sanding head (see section
“Replacing Velcro or backing pad”).
 Loosen the retaining screws.
 Take the ring out of the housing.
 Insert a new brush ring into the housing
and screw in the retaining screws.
 Assemble sanding head in reverse
sequence.

Flex GE 5 Specifications

General

Product color	Black, Red, Silver
Type of sander	-
Adjustable speed	Yes
Idle speed (max)	1650 RPM
Idle speed (min)	1100 RPM
Input power	500 W
Output power	270 W
Power source	AC
AC input voltage	230 V
AC input frequency	50/60 Hz

Weight and Dimensions

Width	1520 mm
Weight	3900 g
Sanding disc diameter	225 mm
