Flex SBG 4910 User Manual

SBG 4910
22
`^rqflk>
oáëâ=çÑ=áåàìêó>=^äï~óë=âÉÉé=óçìê=äÉÑí=Ü~åÇ=
çå íÜÉ=çìíëáÇÉ=çÑ=íÜÉ=ÅìííáåÖ=~êÉ~K
 Take hold of the handle (1) with your right
hand and press the switch. Slowly feed
the saw frame (6) along the material.
 After making the first cut, increase the
pressure. Apply uniform feed through the
material.
 After cutting the material, release the
switch and move the handle to its original
position.
 If required, attach parallel stop (16).
When not in use, fix in the holder under
the machine table (17).
Free-hand sawing
The saw can be removed from the machine
table (17). This allows free-hand sawing
as required (e.g. permanently installed
workpieces).
`^rqflk>
Ó _ÉÑçêÉ=ìëÉI=~äï~óë=ÅÜÉÅâ=íÜÉ=ã~ÅÜáåÉ=
~åÇ=ë~ï=Ä~åÇ=Ñçê=Ç~ã~ÖÉK=
Ó tÜÉå=ë~ïáåÖI=~äï~óë=éä~ÅÉ=íÜÉ=ë~ï=Ä~åÇ=
ÖìáÇÉ=EONF=çå=íÜÉ=ïçêâéáÉÅÉK
Ó pïáíÅÜ=çå=ë~ï=Ä~åÇ=ÄÉÑçêÉ=ÖìáÇáåÖ=
íçï~êÇë=íÜÉ=ïçêâéáÉÅÉK=
kÉîÉê=ëïáíÅÜ=çå=íÜÉ=éçïÉê=íççä=ïáíÜ=
íÜÉ ë~ï=Ä~åÇ=çå=íÜÉ=ïçêâéáÉÅÉ>
 Loosen wing nut (11) and pull saw out of
the dovetail guide (9).
 Switch on the device.
 When sawing, always hold the saw with
both hands.
 Place saw band guide (21) on the
material.
 Press the switch. Slowly feed the saw
band (19) along the material.
 After making the first cut, increase
the pressure. Apply uniform feed
through the material.
 After cutting, release the switch.
 After working, re-attach the saw
to the machine table.

Flex SBG 4910 Specifications

General

Product color	Black, Metallic, Red
Built-in light	-
Adjustable speed	Yes
Number of speeds	2
Input power	850 W
Cable length	4 m
Output power	445 W
Power source	AC
AC input voltage	230 V
AC input frequency	50/60 Hz
Blade width	13 mm
Blade length	1335 mm
Blade thickness	0.65 mm

Weight and Dimensions

Depth	310 mm
Width	640 mm
Height	390 mm
Weight	18000 g
