Instruction manual XFE 7-15 / XCE 10-8
10
Overview
1 Grip hood
With air outlet and direction-of-rotation
arrow.
2 Gear head *
3 4.0 m (13 ft.) power cord with plug
4 Dial for preselecting the speed
5Switch
Switches the power tool on and off and
also accelerates it up to the
preselected speed.
6 Locking button
Locks the switch (5) during continuous
operation.
7 Rating plate *
8 Velcro pad
9 Disc support
Torx wrench T20 *
* not illustrated
