Use of tap lubricator system
FlexArm mounts a standard tap lubricator system in its tapping units. [Refer to diagram]
• Connect air inlet and arm pneumatic tube to the regulator-manometer which is adjusted in our factory.
• Fill oil tank located in front lower arm: uncover the filler plug and fill with tapping oil to the maximum level.
• Press and hold the starting lever until you see atomized oil begin to leave for the lance tip. The first time, the
atomized oil will take time to reach the lance tip, but later uses will be much quicker.
• Adjust the quantity of oil mixture released by adjusting the oil regulator mounted behind lance.
• The tap lubricator system can be used before, during and after tapping pieces.
Oil regulator
Oil tank
Filler plug
Lance
Regulator, manometer
Starting lever
Caution! Don´t use corrosive oil, It can damage the system's plastic valves.
