INSTRUCTION HANDBOOK
FS10, FS32
FS10-32 IH EN 74-310-002 v1.04.doc Version: 1.04 Page 7 of 16
2.4.2 Buttons / Connections
ON/OFF Button / Emergency stop
Power indicator; lights when power is on.
OFF is used for emergency stopping.
Power supply connection
Compressed air connection
Exhaust filter and air collection
Air tubes for the crimp head
