INSTRUCTION HANDBOOK
FS10, FS32
FS10-32 IH EN 74-310-002 v1.04.doc Version: 1.04 Page 8 of 16
2.4.3 Services
All electrical systems are placed inside the machine.
Power supply: 110/230 VAC earthed,
50/60Hz
Consumption: 50 W
Compressed air: 0,6 MPa / 6 bar, clean and dry air
Consumption, FS10:
35 L/min. free air
Consumption, FS32:
50 L/min. free air
Note:
Only authorised personnel can gain access to the installations. The main
power cable must be removed completely from power supply before the
installations are touched.
2.4.4 Bottles and caps
Bottle sizes
FS10 FS32
Max. Diameter 55 mm 95 mm
Max. Height 180 mm 240 mm
Cap sizes
FS10 FS32
DIN standard
With or without
flip-top
8-20 mm 20-32 mm
2.4.5 Ingress protection
Ingress protection IP31
2.4.6 Weight
Weight, FS10 app. 12 kg
Weight, FS32 App. 16 kg
2.4.7 Materials
Cabinet
Anodised aluminium
Closing head
Hardened steel jaws
Anodised aluminium housing
