15
7.4 Capacity Diagram, Sound Data, Specifications - Flexit L30 X W/E
Supply air side (with F7 filter)
Data for supply air is measured in accordance with ISO 5136,
the “In duct method”.
Radiated noise is measured in accordance with ISO 9614-2.
Bruel & Kjær measuring equipment, type 2260.
Blue curves: Air capacity at various capacity settings in Volt.
Green curves: Supply air fan power consumption at various capacity
settings.
Red curves: Sound power level Lw
A, cf. correction table.
Light blue correction axis: Pressure increase using an EU-5 filter.
Light green correction axis: Pressure reduction using a water battery.
Sound data is given at sound power level LwA in the
capacity diagrams and is corrected with the table below
for the various octave bands. Radiated noise produces
Lw in the various octave bands and total LwA. This is read
directly from the supply air table.
Correction factor for LwA
Hz 63 125 250 500 1000 2000 4000 8000 LwA
Supply air 1 -7 0 -3 -4 -11 -19 -30
Extract air 16 6 -4 1 -14 -22 -33 -42
Radiated -28 -34 -30 -26 -26 -28 -34 -47 -21,7
Extract air side (with F7 filter)
Power consumption in Watt
Contact resistance (Pa)
Air flow rate, m
3
/h - Pressure correction factor
Power consumption in Watt
Contact resistance (Pa)
Air flow rate, m
3
/h - Pressure correction factor
0
Water Battery
F5-filter
-5 -10 -20 -35
-50
0
200
400
600
800
Pa
l/s
0
250 500
750
1000
0
2000 4000
m
3
/h
1000 3000
Pa
15 30 45
60
75
0
1000
W
0
400
800
1000
600
200
1200
87dB(A)
Max
80dB(A)
75dB(A)
Max
80%
40%
85dB(A)
80%
60%
40%
60%
0
200
400
600
800
Pa
l/s
0
250 500
750
1000
0 2000 4000
m
3
/h
1000 3000
Pa
F5-filter
15
30
45
60
75
0
1000
W
0
400
800
1000
600
200
1200
62dB(A)
Max
55dB(A)
50dB(A)
Max
80%
40%
60dB(A)
80%
60%
40%
60%
