Status of inputs:
INPUT1 INPUT2 INPUT3 INPUT4
27/03/13-09:45:00 0 0 0 0
27/03/13-10:00:00 0 0 0 1
Device at address 2:
Measured tension values:
U1 U2
MIN MAX AVG MIN MAX AVG
27/03/13-09:45:00 160 V 320 V 260 V 520 V 580 V 540.00 V
27/03/13-10:00:00 40 V 60 V 55 V 1020 V 1080 V 1050.00 V
7.6 Modbus Alarms
A variable declared as an alarm (action eld = 8 for the variable in the denition le) causes an alarm to
be triggered if its’ status changes. This alarm is written to a le in CSV format. This le is compressed into
GZ format, then uploaded to the FTP server at the next acquisition time.
7.6.1 Alarm Filename Syntax
The alarm le uploaded to the FTP server complies with the following format:
prexID_AL_YYMMDD_hhmmss.csv.gz
Where:
prexID: gateway identier.
YYMMDD_hhmmss: timestamp of the archive in the format “year-month-day-
hour-minute-second”.
