5. Xtender Monitoring Program for PC
 INTEGRATED MONITORING PROGRAM FOR PC
Integrated PC Monitoring Program can provide Xtender more efficient control. Log files will be
saved in PC as well as SD Memory Card.
 Integrated Monitoring program for PC can control the Xtender and manage the operation data easily
by using integrated router.
 BMS (Battery Monitoring System) can be synchronized w
ith the Xtender through this program.
 Integration Router
Operation indicator
• Power : Red LED
• Bluetooth : Blue LED
BMS Antenna
DC 5V
(Not needed with USB connection)
USB Port (Server to PC)
Serial Port (Server to Xtender)
(Not needed when using Bluetooth)
Bluetooth Antenna
