2. eCal procedure steps: Descriptions
Step 1 START eCal
Command: @011000000001020001EB Start the eCal process.
Response: @011000000001EE ACK
Step 2. Total Load cell Emax entry
Command: @01100003000204000001F4F1 Total LC is 500kg.
Response: @011000030002EA ACK
Step 3. Average Load cell mV/V entry
Command: @0110000500020400004E2F67 LC sensitivity: 2.0015mV/V.
Response: @011000050002E8 ACK
Step 4. Estimated Dead load entry
Command: @0110000700020400000000E2 Dead load is 0kg.
Response: @011000070002E6 ACK
Step 5. Scale Capacity entry
Command: @01100009000204000000FAE6 Scale capacity is 250kg.
Response: @011000090002E4 ACK
Step 6. SAVE with estimated dead load value
Command: @011000000001020007E5 Save the eCal values.
Response: @011000000001EE ACK
Or SAVE with automatic zero adjustment.
Unload the scale and send the command below
to start the zero adjustment.
Command: @011000000001020015D7 Save eCal with Zero Adj
Response: @011000000001EE ACK
Step 7. APPLY
Command: @011000000001020009E3 Apply the calibration.
Response: @011000000001EE ACK
Step 8. STOP eCal
Command: @011000000001020002EA Stop the eCal process
Response: @011000000001EE ACK
3. Digital Filter Setting:
Command: @011000220001020000CA Set the Fast filter
Command: @011000220001020001C9 Set to Medium filter
Command: @011000220001020002C8 Set to Slow filter
Response: @011000220001CC ACK
