FLIR A655sc - Explanation; Figure

Example system overviews12
12.1.3 Figure
12.1.4 Explanation
1. Computer.
2. CAT-6 Ethernet cable with RJ45 connectors.
3. Industrial Ethernet switch.
4. FLIR A6xx cameras.
5. Industrial process to be monitored, e.g., a gasifier.
12.1.5 Figure
#T559950; r. AD/35720/35720; en-US
18
