FLIR A6703 - Performance Characteristics; A858 x Performance

7 – Specifications
A6000 and A8500 Series User’s Manual 81
Overlay
Available on HD-SDI output
Palettes
Selectable
• Grayscale
• Various color palettes
Zoom (HD-SDI video)
• Automatic, best fit
7.5 Performance Characteristics
7.5.1 A858x
Power Consumption
FLIR PWR Supply @ 120V
AC
Continuous Cool Down:
50 VA
Continuous Normal:
41 VA
Power Consumption
Camera DC Power @ 24V
DC
Continuous Cool Down:
24 Watts
Continuous Normal:
21.25 Watts
Cool-down Time
≈5-7 minutes to reach operating temperature
Sensitivity (w/o optics)
NEΔT
1
1.5-5.0 µm: ≤ 30mK typical
3.0-5.0 µm: ≤ 25mk typical
1) NET is at 50% nominal bucket fill, 298K background, + 5
o
C signal
7.5.2 A6000 Series
Specifications
A670x
A675x
A678x
A675x SLS
A678x SLS
A626x
Power Consumption
FLIR PWR Supply @ 120V
AC
Continuous Cool Down: 50VA
40VA
Continuous Normal: 41VA
36VA
Power Consumption
Camera DC Power @ 24V
DC
Continuous Cool Down: 24W
21W
Continuous Normal: 22W
19W
Cool-down Time
≈5-7 minutes
≈2
minutes
Sensitivity (w/o optics)
3-5m: ≤20mK
≤45 mK
N/A
