FLIR EX Series User Manual

Technical data9
9.5 FLIR E4 (incl. Wi-Fi)
P/N: 63906-0604
Rev.: 40418
General description
The FLIR Ex series cameras are point-and-shoot infrared cameras that give you access to the infrared
world. A FLIR Ex series camera is an affordable replacement for an infrared thermometer, providing a
thermal image with temperature information in every pixel. The new MSX and visual formats make the
cameras incomparably easy to use.
The FLIR Ex series cameras are user-friendly, compact, and rugged, for use in harsh environments. The
wide field of view makes them the perfect choice for building applications.
Benefits:
• Easy to use: The FLIR Ex series cameras are fully automatic and focus-free with an intuitive interface
for simple measurements in thermal, visual, or MSX mode.
• Compact and rugged: The FLIR Ex series cameras’ low weight of 0.575 kg and the accessory belt
pouch make them easy to bring along at all times. Their rugged design can withstand a 2 m drop test,
and ensures reliability, even in harsh environments.
• Ground breaking affordability: The FLIR Ex series cameras are the most affordable infrared cameras
on the market.
Imaging and optical data
IR resolution 80 × 60 pixels
Thermal sensitivity/NETD <0.15°C (0.27°F) / <150 mK
Field of view (FOV)
45° × 34°
Minimum focus distance 0.5 m (1.6 ft.)
Spatial resolution (IFOV)
10.3 mrad
F-number 1.5
Image frequency 9 Hz
Focus Focus free
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
7.5–13 µm
Image presentation
Display 3.0 in. 320 × 240 color LCD
Image adjustment
Automatic adjust/lock image
Image presentation modes
Image modes Thermal MSX, Thermal, Picture-in-Picture, Ther-
mal blending, Digital camera.
Multi Spectral Dynamic Imaging (MSX)
IR image with enhanced detail presentation
Picture-in-Picture IR area on visual image
Measurement
Object temperature range –20°C to +250°C (–4°F to +482°F)
Accuracy ±2°C (±3.6°F) or ±2% of reading, for ambient tem-
perature 10°C to 35°C (+50°F to 95°F) and object
temperature above +0°C (+32°F)
#T559828; r. AK/40423/40448; en-US
35
