FLIR K Series Notice To End Users

Notice to customer
Flir K series In-truck charger
© 2013, Flir Systems, Inc.
#T559801; r. 6533/6533; en-US
5 Mounting instructions
Follow this procedure:
1. Permanently install a cable running from the fire engine’s 12–24 VDC system to the
selected mounting position of the in-truck charger. Do not connect this cable to the
12–24 VDC system at this time. The routing must include a fuse installed close to the
battery. See above for the fuse recommendation.
2. Remove the two screws that hold the metal bracket.
3. Remove the metal bracket.
4. Use the metal bracket as a template to mark where the mounting holes should be
drilled.
5. Drill the holes.
6. Mount the metal bracket using the rivets and/or screws that come with the in-truck
charger.
7. Connect the cable to the cable plinth on the rear of the in-truck charger.
Note
Take note of the polarity when you connect the cable to the cable plinth.
8. Route the cable so that it exits through the cable port of your choice.
9. Mount the in-truck charger to the metal bracket using the two screws that you re-
moved in Step 2. above.
10. Permanently connect the cable to the fire engine’s 12–24 VDC system.
6 Charging the camera
Follow this procedure:
1. Pull up the top cover of the in-truck charger.
2. Push the camera into position.
3. Push down the top cover.
The charging of the camera has now started, and is finished when the blue light
glows continuously. Charging a fully depleted camera takes approximately 4 hours.
7 Charging a battery separately
Flir K series batteries can be charged separately using the battery charger at the lower
front of the unit.
Follow this procedure:
1. Pull the eccentric latch on the bottom of the camera.
2. Pull out the battery from the camera.
3. Push the battery into the slot at the lower front of the charger.
4. Secure the battery using the eccentric latch on the charger.
The charging of the battery has now started, and is finished when the blue light glows
continuously. Charging a fully depleted battery takes approximately 4 hours.
8 Technical data
Dimensions (height × width × depth) 380 mm × 180 mm × 153 mm (15″ × 7.1″ × 6″)
Weight 2.2 kg (4.8 lb)
Power input
12–24 VDC
Charging time (camera) ≈ 4 hours
Charging time (separate battery) ≈ 4 hours
3 (4)
