FLIR SC5000 User Manual

Advanced Thermal Solutions SC5000 User Manual
DCOO2U-L SC5000 User Manual Page 24
SC5200 USB
SC5700
Detector Materials
InSb
MCT
Spectral Response
3.6-5.1 µm
3.7-4.8 µm
Number or Pixels
320 x 256
640x512 F/4
Pitch
30µm x 30µm
15µm x 15µm
Sub Windowing
160x120 /
80x60 /
64x8
320x256 /
160x128 /
User Defined
Frame Rate
5Hz to 120Hz Full Frame
11kHz @64x8
1Hz to 115Hz Full Frame
2.9kHz @132x3
Image Capture
Snapshot Integrate then Read mode (ITR)
Cooling Type
Integral stirling cooler
Cooling Time
< 7mn @ 25°C ambient
Camera External Trigger
LVTTL (<300ns Jitter)
LVTTL (<100ns Jitter)
Frame rate resolution
1 Hz step
Integration Time
3 µs to 20000 µs
programmable, 1 µs Step
0.1 µs to 20000 µs
programmable, 0.1 µs
Step
NETD
<30 mK (25 mK Typical)
<25 mK (20 mK Typical)
Power Supply
12 VDC / 5A
Power consumption
30W in cool down mode, 25W in steady state mode
Digital Video
USB 2.0
GigE / Camera LINK
Analog Video
PAL (50 Hz) or NTSC (60 Hz)
Remote Control
USB 2.0
GigE / Camera LINK
Overall dim, (mm)
310 x 141 x 159
Weight (W/O lens)
3.8 kg
Water & humidity
IP54
Operational temperature
range
-20°C +55°C

FLIR SC5000 Specifications

General

Brand	FLIR
Model	SC5000
Category	Thermal cameras
Language	English
