FLIR TG165-X User Manual

Introduction
2
The FLIR TG267, TG297, and TG165–X are Diagnostic Thermal Cameras
which combine non-contact temperature measurement and thermal imaging
into one troubleshooting tool to help you quickly find the source of heat-re-
lated problems and spot potential faults.
The FLIR TG267 adds Type-K thermocouple contact temperature
measurements.
The FLIR TG297 offers a high temperature range to 1030℃ (1886℉).
Visit https://support.flir.com/prodreg to register your instrument and to extend
the standard one-year warranty to the 2-10 Year Warranty.
Features
• See beyond the limitations of single-spot IR thermometers with a 160 x 120
pixels (80 x 60 pixels, for TG165–X) true thermal imager (Lepton® micro-
bolometer with integrated shutter)
• Visible spectrum 2M pixel digital camera
• Adjustable MSX® (Multi-Spectral Dynamic Imaging) adds key details from
the visible spectrum camera to the IR image to help you diagnose
problems
• 3 presets and 1 custom emissivity setting
• LED Work light
• Laser pointer and cross-hair display for easy targeting of measurement
spot
• Type-K thermocouple contact measurements (TG267)
• High temperature lever switch (TG297) engages high temperature mode
• 4 GB internal memory for storing captured images
• USB–C connectivity for image transfer and charging
• Bluetooth® real-time remote temperature monitoring and camera image
transmission to mobile devices (TG267, TG297 only)
• Easy to read 320 x 240 2.4” TFT colour LCD display
• Intuitive programming menu system translated in more than 21 languages
• IP54 enclosure (with top flap closed) protects from dirt, dust, and oil
• Rechargeable lithium battery
• Auto power off (APO), user adjustable
• Accessory mounting for tripods, extender poles, etc.
#NAS100014; r. AJ/68076/68076; en-US
2

FLIR TG165-X Specifications

General

Internal storage capacity	4 GB
Sensor type (thermal module)	-
Temperature measurement range	-25 - 300 °C
Image sensor size	2/3 \
Sensor resolution (thermal module)	80 x 60 pixels
Display type	LCD
Certification	CE/CB/EN61010/UL
Product color	Black
Built-in display	Yes
Display diagonal	2.4 \
Display resolution	320 x 240 pixels
Operating temperature (T-T)	-10 - 45 °C
Battery capacity	- mAh
Battery life (max)	5 h
Battery recharge time	6 h
Package depth	151 mm
Package width	284 mm
Package height	105 mm
Package weight	94 g

Weight and Dimensions

Depth	64 mm
Width	219 mm
Height	81 mm
Weight	40 g
