USER MANUAL - Rev 1
THERMOSIGHT PRO PTS233 THERMOSIGHT PRO PTS536 THERMOSIGHT PRO PTS736
USER INTERFACE
Operation Switch On/ Off/ Standby Mode
Control Panel Buttons
Congures Operational Settings:
• Display Brightness Control
• Image Palette Control
• Digital Zoom Control
• Reticle Pattern Control
• Reticle Color Control
• Boresighting Adjustment
• On-Screen Menu Navigation
Diopter Adjustment Ring Adjusts the Eyepiece Diopter
Focus Ring Not available Adjusts the Objective Lens Focus
INTERFACING
USB-C Connector Digital video out; Video and image le access
POWER
Battery Type Two CR123A 3V Lithium batteries
Battery Life (Operating) Up to 4 hr at 20°C
External Power Through USB-C port (5 Vdc)
ENVIRONMENTAL
Operating Temperature Range -20°C to +50°C (-4°F to +122°F)
Storage Temperature Range -40°C to +60°C (-40°F to +140°F)
PHYSICAL
Weight 0.65 kg (1.44 lbs) 0.81 kg (1.78 lbs) 0.97 kg (2.14 lbs)
Size
220 × 84 × 68 mm
(8.7 × 3.3 × 2.7 in)
259 × 84 × 68 mm
(10.2 × 3.3 × 2.7 in)
283 × 93 × 89 mm
(11.1 × 3.7 × 3.5 in)
Weapon Mount Type Picatinny, MIL-STD 1913, and Weaver Rails
Height of the Scope Axis above
Rail
42 mm (1.65 in) 42 mm (1.65 in) 48 mm (1.89 in)
Color (housing) Black
Country of Origin USA
PACKAGES INCLUDE
Thermal Weapon Sight, Batteries (2), Battery Cassette, USB to USB Type C Cable (3’), Quick Start Guide, Cleaning Cloth, Hard Case
SPECIFICATIONS TABLE CONTINUED
