Floe V2600-VSD5000 - Page 3

SHEET 3 OF 12
BILL OF MATERIALS - BUNKS
P/N
111
-
00370
-
00
P/N 111-00371-00
P/N 111-00385-00
P/N 111-00386-00
P/N 111-00413-00
P/N 111-00414-00
ASS’Y, BUNK
–
PONTOON 192” (A)
ASS’Y, BUNK – PONTOON 192” (B)
ASS’Y, BUNK – PONTOON 216” (A)
ASS’Y, BUNK - PONTOON 216” (B)
ASS’Y, BUNK – PONTOON 240” (A)
ASS’Y, BUNK – PONTOON 240” (B)
NUMBER PART NUMBER QTY. DESCRIPTION
10 111-00370-00 1 ASS’Y, BUNK – PONTOON 192” (A)
A 001-29825-00 11 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
10A 958-00320-00 1 PVC, BUMPER EXTRUSION – 204.5”
11 111-00371-00 1 ASS’Y, BUNK – PONTOON 192” (B)
A 001-29825-00 11 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
11A 958-00320-00 1 PVC, BUMPER EXTRUSION – 204.5”
12 111-00385-00 1 ASS’Y, BUNK – PONTOON 216” (A)
A 001-29825-00 12 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
12A 958-00322-00 1 PVC, BUMPER EXTRUSION – 228.5”
13 111-00386-00 1 ASS’Y, BUNK – PONTOON 216” (B)
A 001-29825-00 12 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
13A 958-00322-00 1 PVC, BUMPER EXTRUSION – 228.5”
14 111-00413-00 1 ASS’Y, BUNK – PONTOON 240” (A)
A 001-29825-00 13 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
14A 958-00323-00 1 PVC, BUMPER EXTRUSION – 252.5”
15 111-00414-00 1 ASS’Y, BUNK – PONTOON 240” (B)
A 001-29825-00 13 SCREW, 10-24 X 1” SQWFRTEK
B 001-71000-00 2 FLAT WASHER, 5/16 ID X 7/8” OD SS
15A 958-00323-00 1 PVC, BUMPER EXTRUSION – 252.5”
