INSTALLATION
TILT BRACKETS / RECIEVER MOUNT / ACTUATORS
STEP 1
512-65000-00 (VSD 5000)
-PLACING CANOPY LEGS
INSERT A CANOPY LEG (INCLUDED IN CANOPY HOOP
(INCLUDED IN CANOPY HOOP(INCLUDED IN CANOPY HOOP
(INCLUDED IN CANOPY HOOPS
SS
S)
))
) IN EACH OF THE CORNER
POSTS.
..
. TILTING LEGS (002-00156-00, SHOWN BELOW) ARE PLACED IN PIVOTING SIDE
(SHORE-END) CORNER POSTS. NON-TILTING LEGS (911-14203-00) ARE PLACED IN
NON PIVOTING SIDE CORNER POSTS. ATTACH USING A ½-13 x 1 1/4” BOLT, FLAT
WASHER, AND NYLOCK NUT (INCLUDED
(INCLUDED(INCLUDED
(INCLUDED WITH CANOPY HOOP
WITH CANOPY HOOPWITH CANOPY HOOP
WITH CANOPY HOOPS
SS
S)
))
) (FIG.1).
PLACE BOLT AND WASHER IN CORNER POST (FIG.2).
SLIDE CANOPY LEG INTO CORNER POST. BOLT AND WASHER ARE INSERTED INTO
CANOPY LEG NUT TRACK (FIG. 3).
PLACE NUT ON BOLT. TORQUE TO
TORQUE TOTORQUE TO
TORQUE TO 60 FT/LBS
60 FT/LBS60 FT/LBS
60 FT/LBS.
. .
. LEG MUST BE INSERTED TO HAVE 18
LEG MUST BE INSERTED TO HAVE 18 LEG MUST BE INSERTED TO HAVE 18
LEG MUST BE INSERTED TO HAVE 18
INCHES ABOVE CORNER POST
INCHES ABOVE CORNER POSTINCHES ABOVE CORNER POST
INCHES ABOVE CORNER POST (FIG.4).
