Floe VSD 8000 - Page 4

4
continued
Step
Part Numbers
QTY Descriptions Torque
001-70213-00
001-70223-00
001-76072-00
001-70212-00
001-71022-00
002-04241-00
007-07625-00
2
2
7
3
4
1
1
HHCS, 1/2-13 x 2 1/2” ss 18-8
HHCS, 1/2-13 x 5” ss 18-8
NUT, NYLOCK 1/2-13 ALUM.
HHCS, 1/2-13 x 2 1/4” ss 18-8
FLAT WASHER, ½” USS ss 18-8
HOLDER, CABLE – 4” SHEAVE
SHEAVE, 4” CLAMP
80 ft. lbs.
001-70365-00
001-07626-00
001-70817-00
001-70110-00
001-71017-00
001-76071-00
001-70124-00
001-76071-00
1
1
1
4
8
4
4
4
HHCS, 3/4-10 x 3” ss
SHEAVE, 2” CLEVIS
NUT, ¾ - 10 JAM ss
HHCS, 3/8-16 x 1 3/4” ss 18-8
FLATWASHER, 3/8” SAE ss 18-8
NUT, NYLOCK 3/8-16 ALUM.
HHCS, 3/8-16 x 5 1/2” ss 18-8
NUT, NYLOCK 3/8-16 ALUM.
100 ft. lbs.
5 ft. lbs.
25 ft.lbs.
