FLORABEST 73433 - Assembling The Round Handle; Attaching The Shoulder Strap; Installing The Blade; Fitting The Saw Chain


 
Beforeusingthehighpruningsaw,you
must:
-asseblingtheroundhandle
-attachingtheshoulderstrap
-ttingtheblade
-ttingthesawchain
-tensioningthesawchain
-llupwithchainoil
Assembling the Round Han-
dle
TheAllenkey( 26)canbefoundinits
holderonthequickrelease(
H
15).
 1. Setroundhandle(14)tothe
desiredpositiononthetelescopic
handle.
 2. Placebrakearm(7)onthetel-
escopichandle.
 3. Screwtogetherroundhandle(14)
andbrakearm(7).
 4. Theheightorholdingangleof
roundhandle(14)canbeadjust-
edatanytimebyslightlyloosen-
ingthescrews,pushing/turning,
andretighteningthescrews.
Attaching the Shoulder Strap
 Fixthespringhookonshoulder
strap(12)intoliftinglug(13)onthe
telescopichandleoftheequipment.
Installing the Blade
1. Loosenbladexingscrew(4)
andremovechainwheelcover
(6).
 2. Insertblade(2)withthecentral
longitudinalholeovercentral
bladeguide(16).
Fitting the saw chain
 1. Layoutsawchain(1)suchthat
thebevelledcuttingedgesofthe
chainlinkspointinaclockwise
direction.Seethedetailedillus-
tration.
 2. Placesawchain(1)inblade
groove(2)andonchainwheel
(18).
 3. Tofacilitateassembly,position
thechaintensioningpin(21)by
turningthechaintensioner(5)
towardsthebladexingscrew
(4)untilitstops,beforetting
thechainwheelcover(6).
 4. Replacechainwheelcover(6)
andscrewonbladexing(4).
 5. Bladexingscrew(4)issimply
tobetightenedlightlybyhand.
Hole(20)onthebladeisthe
holderforchaintensioningpin
(21).Thread(19)istheholder
forbladexingscrew(4).
 Ensurethatchaintensioningpin
(21)ispositionedinhole(20)on
theblade.Thepinmustbecom-
pletelyinsertedintothehole.
Tensioning the saw chain
Thetensionofsawchain(1)isimportant
bothforyoursafetyandforthefunction
ofthehighpruningsaw.Acorrectlyten-
sionedsawchainwillincreasethelifetime
ofyourequipment.
• Sawchain(1)iscorrectlytensioned
ifitcanbepulledaroundblade2by
hand(wearinggloves)withoutsag-
ging.
• Whenthesawchainistensionedwith
9N(approx.1kg),thegapbetween
