FLORABEST 73433 - Intended.purpose; General.description; Enclosed Parts; Technical.data


 
Intended purpose
Thehighpruningsawisintendedforprun-
ingworkontreebranches.
Itisnotdesignedforextensivesawing
work,treefellingandcuttingmaterialssuch
asmasonry,plasticorfood.
Thedeviceisdesignedforusebyadults.
Youngpeopleover16yearsoldmayusethe
highpruningsawundersupervisiononly.
Itisessentialtoensurethatyouarestand-
inginasafeposition,inordertoprevent
accidents.Theequipmentisnotintendedfor
usebypeopleofrestrictedphysical,sensory
ormentalability.Thisisalsofundamentally
applicableforchildren.
Themanufacturerisnotliablefordamages,
whichwerecausedthroughuseinappli-
cationsforwhichitwasnotdesigned,or
incorrectoperation.
Thehighpruningsawisdesignedforem-
ploymentinthedo-it-yourselfersector.Itwas
notdesignedforcontinuousemploymentin
thecommercialsector.
General description
Theillustrationoftheprincipal
functioningpartscanbefound
onthefrontandbackfoldout
pages.
Enclosed parts
Carefullyunpacktheapplianceandcheck
thatitiscomplete:
-Highpruningsaw
-Chainbar
-Sawchain
-Bladecover
-Shoulderstrap
-Roundhandle
-60mlGrizzly-Bio-Oil
-Allen Key
Overview
 1 Sawchain
 2. Chainbar
 3. Bumber
 4. Bladexingscrew
 5. Chainadjustmentring
 6. Sprocketchainwheelcovering
 7. Brakearm
 8. Pivotalcentre(notvisible)
 9. Adjustablehandle
 10. On/offswitch
 11. Safetylock(notvisible)
 12. Shoulderstrap
 13. Eye(forshoulderstrap)
 14. Roundhandle
 15. Quickrelease(fortelescopichan-
dle)
Technical Data
High pruning saw .....................FHE 550 B2
Ratedinputvoltage.............230V~,50Hz
Inputpower.................................. 550W
Safetyclass........................................
II
Chainspeed............................. 10,8m/s
Weight(withoutguiderail
andchain).....................................4,1kg
Weight(withguiderailandchain)...4,6kg
Oiltank.........................................70cm
3
Chain.......................... Oregon91P040X
Chainpitch3/8“(9,5mm)
Chainbar........ 10“OregonDoubleGuard
100SDEA041(518693)
Numberofchaindrivelinks 40
Chainwidth.................................1,3mm
Teethofthesprocketchainwheel............. 6
Sawinglength(max.)...................260mm
Acousticpressurelevel
(L
pA
)...................88dB(A);K
pA
=3,0dB(A)
Soundpowerlevel(L
WA
)
guaranteed........................ 104,0dB(A)
measured... 102,2dB(A);K
wA
=1,5dB(A)
Vibration(an).......... 3,0m/s
2
;K=1,5m/s
2
