Technical Data AUTOJET 1000 AUTOJET 1500
Mains voltage / frequency 230 V ~ 50 Hz 230 V ~ 50 Hz
Absorbed power 800 Watt 1100 Watt
Type of protection / Insulation class IPX4 / F IPX4 / F
Suction fitting 33,25 mm (1"M) 33,25 mm (1"F)
Delivery fitting 33,25 mm (1"M) 33,25 mm (1"F)
Maximum flow rate 3.300 l/h 4.200 l/h
Maximum head 46 m 45 m
Maximum suction height 7 m including load losses 7 m including load losses
Power cable 1,5 m H07 RNF 1,5 m H07 RNF
Weight 9,8 Kg 10,5 Kg
Maximum admitted working pressure 6 bar 6 bar
Minimum ambient temperature 5° C 5° C
Maximum ambient temperature 40° C 40° C
Maximum temperature of the pumped fluid 50° C 50° C
Maximum number of starts per hour 40, uniformly distributed 40, uniformly distributed
Sound power level (Lwa)** 89 dB 82 dB
Sound pressure level (Lpa) 76,5 70,1
7
GB
GB
2
The pump cannot be used for sea water and inflammable, corrosive, explosive or
dangerous liquids.
Verify that the electropump never runs without liquids.
WARNING
WARNING
Ch. 3 Installation (see Fig. 1)
When installing, please ensure electropump is disconnected from electrical
supply. Pumps in this series are not suitable for use in a swimming pool and
the relevant cleaning and servicing operations.
Protect the electropump and all pipes from bad weather or freezing conditions.
WARNING
Electric shock
risk
DANGER
To prevent possible injuries to people, avoid inserting hands into the mouth of the pump if
this is connected to the mains.
DANGER
Use a suction pump (2) with a diameter equivalent to that of the suction mouth of the electropump (1).
If the height (HA) is over 4 meters use a tube with a larger diameter. The suction line should be perfectly airtight.
No elbows and/or slopes should be present to prevent the formation of air locks that could affect the electropump
efficiency. A foot valve (3) with filter (4) should be fitted at about half a metre below the fluid that has to be pumped (HI)
on one end of the line. Load losses can be reduced using delivery piping with a diameter equivalent or greater than the
electropump mouth (5). It is advisable to install a check valve (6) directly on the delivery line to prevent the electropump
being damaged by "water hammer".
Sound emission values obtained in conformity with the EN 12639 standard
**Measurement method according to EN ISO 3744
(*) The specifications above are referred to a configuration with a free and unreduced delivery mouth.
DANGER
This appliance can be used by children aged 8 years or over and by persons with limited
physical, sensory or intellectual capabilities, or with limited experience and knowledge,
provided that they are supervised or have been instructed in the safe use of the appliance
and are aware of the dangers involved. Children must not be allowed to play with the
appliance. Cleaning and user maintenance must not be carried out by children unless
they are supervised
