Repair Parts 7
For parts or assistance, call Flotec Customer Service at 800-365-6832
4075 1001
14
13
5
12
11
10
8
7
6
4
3A
3B
2
2
1
9B
9A
9C
16
19
15
16
17
17
20
FP5112
Key Part No. FP5112
No. Description Used 1/2 HP
1 Pump Body 1 101P3410
2 O-Ring, Pipe Plug 1 111P0710
3A Priming Plug 1 102P1030
3B Drain Plug 1 102P1030
4 Hose Adapters 2 101P3460
5 O-Ring, Nozzle 1 111P0480
6 Diffuser Assembly 1 101P2840
7 Impeller 1 731S5700
8 Mechanical Seal 1 ZBR00010
9A Handle, R.H. 1 101P2080
9B Handle, L.H. 1 101P2090
9C Screws, Handle 5 121P1510
10 O-Ring, Pump Body 1 111P0700
11 Seal Plate 1 101P1290
12 Intermediate Support 1 731P0330
13 Water Slinger 1 102P0540
14 Motor 1 *
15 Gasket 1 111P1340
16 Capacitor Box (includes Cover, Gasket) 1 102P2830
17 Capacitor Box Screw 8 121P2060
18 Capacitor 1 171P5620
19 Capacitor Cover Gasket 1 111P1350
20 Screws, Pump Body 6 121P1940
* If motor fails, replace entire pump.
