G-Series Motors: 1 Ph, 2-Wire Cable, 60 Hz. Wire Size
Wire Size, AWG
HP Volt 14 12 10 8 6 4 3 2 1 0 00
0.5 115 110 174 278 440 685 1092 1373 1734 2184 2757 3479
0.5 230 438 697 1112 1761 2740 4369 5492 6936 8738 11029
0.75 230 365 581 927 1468 2284 3641 4577 5780 7281 9191 11596
1 230 304 484 772 1223 1903 3034 3814 4817 6068 7659 9663
2-Wire
Motor is supplied with a copper ground wire.
Splice this ground wire to a copper conductor that
matches motor wire size specified in Table III. See
Page 5 for wire splicing instructions.
Permanently ground pump, motor and control box
before connecting power cable to power supply.
Connect ground wire to approved ground first and
then connect to equipment being installed.
Do not ground to a gas supply line.
Fire and electrical shock hazard. If
using a drop wire larger than No. 10 (5.5mm
2
)
(for example, No. 8 (8.4mm
2
) wire) between
pump and control box, run wire to a separate
junction box. Connect junction box to control box
with a No. 10 (5.5mm
2
) or smaller wire (depend-
ing on amp rating of pump – see Table III).
For more information, contact your local code
officials.
WIRING CONNECTIONS:
All wiring must meet National Electrical Code or
Canadian Electrical Code and local code require-
ments.
Use only copper wire when making connections to
pump and control box.
To avoid over-heating wire and excessive voltage
drop at motor, be sure that wire size is at least as
large as size listed in Table III for your horsepower
pump and length of wire run.
NOTICE: When built-in overheating protection is
not provided, use with an approved overload
equipped motor control that matches motor input in
full load amps. Select or adjust overload element(s)
in accordance with control instructions. When
built-in overheating protection is provided, use with
an approved motor control that matches motor
input in full load amperes.
TABLE I: Recommended Fusing Data - 60 Hz.,
Single Phase, 3 Wire Submersible Pump Motors
TABLE II:
Recommended Fusing Data - 60 Hz.,
Single Phase 2 Wire Submersible Pump Motors
INSTALLATION WIRING -
SINGLE PHASE, 3 WIRE
For motors of 1
1
⁄2 HP and above, use
magnetic starter to avoid damage to pressure
switch. Consult factory for wiring information.
See Page 4 for 2 Wire Hookup.
Hazardous voltage. Can shock,
burn, or kill.
Ground control box, all metal plumbing, and motor
frame with copper wire in compliance with local
codes. Use a ground wire at least as large as the
wires supplying power to motor.
Permanently close all unused openings in this and
other equipment.
Disconnect power to control box before working on
or around control box, pipes, cable, pump, or
motor.
3
Fuse Size
HP Volts Stand Dual Elem. C.B.
1/2 230 15 10 15
3/4 230 25 15 20
1 230 30 15 25
1.5 230 40 20 30
All cable lengths meet NEC for jacketed 60°C copper cable. Based on 3-Wire Induction Run requirements; Capacitor Run requirements may vary. Local
code requirements may vary. For aluminum cable, go up two sizes from chart (for example, if the chart calls for No. 10 AWG (6mm
2
) for copper, go to
No. 8 AWG (10mm
2
) for aluminum; the smaller the number, the larger the cable). Use oxidation inhibitors on the connections.
TABLE III: Copper Cable Length in Feet (Service to Motor)
G-Series Motors: 1 Ph, 3-Wire Cable, 60 Hz. Wire Size
Wire Size, AWG
HP Volt 14 12 10 8 6 4 3 2 1 0 00
0.5 230 348 553 883 1398 2175 3467 4359 5505 6935 8753
.75 230 267 425 678 1074 1671 2664 3349 4229 5328 6725 8485
1 230 203 323 515 815 1269 2023 2543 3211 4045 5106 6442
1.5 230 160 254 406 643 1000 1594 2004 2531 3189 4025 5078
3-Wire
Fuse Size
HP Volts Stand Dual Elem. C.B.
1/2 115 30 15 25
1/2 230 15 10 10
3/4 230 15 10 15
1 230 20 15 20
