FlowCon FN.0.2 User Manual

BUS programming of
FlowCon FN.0.2-BUS
When using FN.0.2-BUS actuator and BUS
communication, setting on the Green/GreEQ in
-
sert MUST BE be 5.0.
In this instruction default values are underlined.
Please see FlowCon FN.0.2-BUS Modbus Data
Point List or BACnet PICS for more detailed in
-
formation.
Initiate by setting Baud Rate (register 105 or
MSV.7). Set actuator DIP switches 1-6 to write-
able mode, i.e. 1-1-1-1-1-1-1 and set MAC Ad-
dress via bus communication (register 104 or
AV.28) and proceed by selecting your PICV
valve in register 110 or MSV.8:
Reg. 110 MSV.8 Selected valve
0 1 (generic linear)
1 2 Green.0
2 3 Green.1
3 4 Green.2
4 5 Green.1HF
5 6 GreEQ.0
6 7 GreEQ.1
7 8 GreEQ.2
8 9 (generic EQ%)
9 10 user-valve
And select your PICV control mode in register
103 or MSV.13:
Reg. 103 MSV.13 Selected control mode
0 0 (linear)
1 1 Equal%
Set Operating Mode in register 200=0 or
MSV.4=1 and provide Control Signal in register
400 or AV.1 (0% to 100%).
Condition of the FN.0.2-BUS
through BUS
Check the Current Flow (not measured) in
register 402 or AI.7.
Status Information is available in BI.3 and
Error Information is available in BI.4, BI.5,
BI.6 and BI.7. This is combined for Modbus in
register 318 and 407.
Service Commands and resetting is avail
-
able in register 138 or MSV.1
FlowCon FN.0.2, FN.0.2-BUS and FN.0.4
1B95080 - 01/2023
This paper is a supplement to the FlowCon General Instruction
Latest release of any FlowCon material is available on www.owcon.com
Page 7 of 8
