Alarm Menu
To enter the alarm menu, simultaneously press
and
for 6 seconds. The alarm menu is
only accessible if an alarm is present (i.e. when the icon
⚠
is displayed). Press
to go to the next
alarm display and press
to go to previous.
For fast menu exit press
and
simultaneously for 6 seconds. The actuator will automatically
return to normal operation mode if no action is detected on arrow keys for 1 minute.
If the actuator is still functioning (= warning code 01, 04, 05 with failsafe and 07 with failsafe),
the
⚠
icon will blink. If the actuator is NOT functioning (=error code 01, 03, 05, 06 with failsafe
and 08), the
⚠
icon is fully on. Error codes will be shown in the information part of the actuator
display.
Display Description Action
Alarm.
Enter password. If enabled in programming menu step 11
Disabled by default. Password: 3569266.
Code
Icon Description Details
01
Valve/actuator is overtorqued. Operation is stopped. Actuator will retry operation every
4 minutes. If over torque condition
disappear, error will convert to error code 02.
02
Actuator has reached its torque limit in
the past.
Actuator is functioning.
To reset the alarm simultaneously press
and
for 6 seconds.
03
Critical - over temperature. Critical: Temperature in actuator is at least 70ºC, motor
operation is stopped. If temperature is decreasing,
operation will resume.
04
High temperature. Actuator is still functioning. Temperature in actuator is at
least 50ºC as limited according to tech note. If tempera
-
ture is decreasing, operation will resume.
05
No Failsafe: Power supply not in range. Operation is stopped. Alarm will automatically reset
when voltage is back in range.
With Failsafe: Power supply not de
-
tected / not in range.
Failsafe is activated. Alarm will automatically reset
when voltage is back in range.
06
Control signal not detected. Operation is stopped. Alarm will automatically reset
when control signal is back in range.
07
Battery error. Battery is not properly connected. Alarm will reset when
battery is properly connected.
Only valid for failsafe actuators.
08
BACnet fallback mode BACnet control value has not been updated and BAC
-
net fallback timeout has been reached. Alarm will reset
when BACnet control signal is refreshed.
Only valid for BACnet actuators.
FULL ON
BLINKING
BLINKING
BLINKING
BLINKING
FULL ON
FULL ON
FULL ON
FULL ON
FlowCon SM 15-250 mm (1/2”-10”)
1A95106 - 01/2019
This paper is a supplement to the FlowCon General Instruction
Latest release of any FlowCon material is available on www.owcon.com
Page 7 of 8
