SL-5200 with Circulation Through a Supply Tank with Cooling Coil Figure 7

pressure source,

normally open

liquid ﬁll,

normally closed

level

transmitter

pressure

transmitter

oriﬁce

1.2 m (4 feet) max

0.91 m

(3 feet)

min

Supply Tank with

cooling coils

drain,

normally closed

cooling in and out
