Fluance Ai60 Quick Start Guide
Front & Back Panel Layout
1. Control Knob
• Volume
• Input Selection
• Power ON/OFF
2. Source LED
• Blue (Solid) - Bluetooth
®
Paired
• Blue (Flashing) - Bluetooth
®
Pairing Mode
• Yellow (Solid) - RCA
• White (Solid) - Optical
• Purple (Solid) - USB
• Red (Solid) - Standby Mode
• Red (Flashing) - Mute
• Red (Flash x1) - Max Volume
• Red (Flash x2) - Bass/Treb Set to -6 or +6
• Source Color: Blue/Yellow/White/Purple
(Flash x2) - Bass/Treb Set to 0
3. IR Sensor
4. Speaker Input
5. Bluetooth
®
Reset Pairing
6. USB Input (Audio Playback Only)
7. Optical Input
8. RCA Input
9. Subwoofer Output
10. Left Speaker Output
11. DC Input
Remote Control Layout
12. Power ON/OFF
13. Volume UP/DOWN
14. Source
15. Treble UP/DOWN
16. Mute
17. Play/Pause & Bluetooth
®
Pairing Reset*
*To enable Bluetooth
®
Pairing Reset, press + hold for 3 seconds.
18. Forward/Back
19. LED Brightness - (100% > 25% > OFF)
20. Bass UP/DOWN
1
2
3
5
6
7
8
9
10
11
4
VOL +
