Doc. No. 06EN003291 Rev. A A - 1 Model ST98 Flow Meter
APPENDIX A - DRAWINGS FLUID COMPONENTS INTL
Appendix A. Drawings
All dimensions are shown in inches. Brackets [ ] indicate dimensions in millimeters.
Figure A-1. Local Enclosure, NEMA Type 4X and Hazardous Location (Aluminum Enclosure Shown)
Figure A-2. Remote Aluminum Double Ended Enclosure NEMA 4X and Hazardous Location
Ø4.68
[119]
LOCAL ENCLOSURE
ALUMINUM (STANDARD)
SST (OPTIONAL)
FLOW ELEMENT PORT
EXTERNAL EARTH
GROUNDING SCREW
3/4 INCH NPT PORT
COVER LOCK
4.82
[122]
POWER
SIDE
ELECTRONICS
SIDE
2X 3/4 IN. NPT
CONDUIT PORTS
OPTIONAL
WINDOW
3/4 IN. NPT CONDUIT PORT
4.00
[101.60]
9.31
[236.47]
COVER LOCK
Ø4.80
[121.92]
