Fluke 117C User Manual

True-rms Multimeters
Rotary Switch Positions
7
Rotary Switch Positions
Switch
Position
Measurement Function Model
x
Automatically selects ac or dc volts based on the sensed input with a low
impedance input.
117C
e
Hz (button)
AC voltage from 0.06 mV to 600 V.
Frequency from 5 Hz to 50 kHz.
115C & 117C
115C & 117C
D
DC voltage from .001 V to 600 V. 115C & 117C
l
AC voltage from 6.0 to 600 mV, dc-coupled. DC voltage from 0.1 to 600 mV.
115C & 117C
Ω
Ohms from 0.1 Ω to 40 MΩ.
115C & 117C
s
Continuity beeper turns on at <20 Ω and turns off at >250 Ω. 115C & 117C
R
Diode Test. Displays OL above 2.0 V. 115C & 117C
S
Farads from 1 nF to 9999 μF. 115C & 117C
j
Hz (button)
AC current from 0.1 to 10 A (>10 to 20 A, 30 seconds on, 10 minutes off).
>10.00 A display flashes. >20 A, OL is displayed. DC-coupled.
Frequency from 45 Hz to 5 kHz.
115C & 117C
I
DC current from 0.001 A to 10 A (>10 to 20 A, 30 seconds on, 10 minutes off).
>10.00 A display flashes. >20 A, OL is displayed.
115C & 117C
w
Non-contact sensing of ac voltage.
117C
Note: All ac functions and Auto-V LoZ are true-rms. AC voltage is ac-coupled. Auto-V LoZ, AC mV and AC
amps are dc coupled.
