Fluke 430 Series User Manual

Specifications continued
Accuracy, resolution and range
Volt/Amps/Hertz Measurement range Resolution Accuracy
Vrms (AC+DC) 1 to 1000 Vrms 0.1 Vrms ± 0.5 % of nominal voltage
Vpk 1 to 1400 Vpk 1 V 5 % of nominal voltage
CFV 1.0 to > 2.8 0.1 ± 5 %
Arms (AC+DC) 0 to 20,000 Arms
1
0,001 to 10 Arms
1
± 1 % of reading ± 5 counts
3
with included clamps 0 to 400 Arms 0.1 and 1 Arms
Apk using 1mV/A scaling 0 - 5500 Apk 10 A ± 5 %
CFA using 1mV/A scaling 1 to 10 0.1 ± 5 %
50 Hz nominal 42.50 to 57.50 Hz 0.01 Hz ± 0.1 % of nominal frequency
60 Hz nominal 51.00 to 69.00 Hz 0.01 Hz ± 0.1 % of nominal frequency
Dips and swells
Vrms
1
⁄
2
(AC+DC) 0.0 to100 % of nominal voltage 0.1Vrms ± 1 % of nominal voltage
Arms
1
⁄
2
(AC+DC) 0 to 20,000 Arms
1
0,001 Arms to 10 Arms ± 1 % of reading ± 5 counts
3
with included clamps 0 to 400 Arms 0.1 Arms and 1 Arms
Threshold levels Programmable in percent of nominal voltage
Duration hhh,mm,ss,mmm with half-cycle cycle time resolution
Harmonics
Harmonic selection (n) DC, 1 to 50
Inter-Harmonic selection Off, 1 to 49
Vrms Relative (%f): 0.0 to 100.0 % 0.1 % ± 0.1 % ± n x 0.1 %
(± 0.4 % for %r)
Absolute: 0.0 to 1000 Vrms 0.1 Vrms ± 5 % of reading ± 2 counts
Arms Relative (%f): 0.0 to 100.0 % 0.1 % ± 0.1 % ± n x 0.1 %
(± 0.4 % for %r)
Absolute: 0.0 to 4000 mV x selected 1 mVrms x selected clamp scaling ± 5 % of reading ± 5 counts
clamp scaling
Watts Relative: 0.0 to 100.0 % 0.1 % ± n x 2 %
Absolute: depends on selected clamp ± 5 % of reading ± n x 2 %
and voltage scaling of reading, ± 10 counts
DC voltage Relative: 0.0 to 100.0 % 0.1 % ± 1 %
Absolute: 0.0 to 1000 V 0.1 V ± 5 % of reading ± 10 counts
THD 0.0 to 100.0 % 0.1 % ± 2.5 %
Hz 0 to 3500 Hz 1 Hz ± 1Hz
Phase angle -360 º to +360 º 1 º ± n x 1.5 º
Power and Energy
Watt
1.0 W to 20.00 MW
1
0.1 W to 1 kW
1
± 1
.5 % of reading ± 10 counts
3
V
A 1.0 VA to 20.00 MVA
1
0.
1 VA to 1 kVA
1
±
1.5 % of reading ± 10 counts
3
V
AR 1.0 VAR to 20.00 MVAR
1
0.
1 VAR to 1 kVAR
1
±
1.5 % of reading ± 10 counts
3
kWh 00.00 kWhr to 200.0 GWhr
1
0.01 Whr to 100 Whr
1
± 1.5 % of reading ± 10 counts
3
kVA 00.00 kVAhr to 200.0 GVAhr
1
0.01 VAhr to 100 VAhr
1
± 1.5 % of reading ± 10 counts
3
kV
AR 00.00 kVARhr to 200.0 GVARhr
1
0.0
1 VARhr to 100 VARhr
1
±
1.5 % of reading ± 10 counts
3
Power Factor 0 to 1 0.01 ± 0.03
3
Cos ϕ / DPF 0 to 1 0.01 ± 0.03
3
Flicker
Pst (1min), Pst, Plt, PF5 0.00 to 20.00 0.01 Within ± 5 % of tabulated values
instantenous Flicker according IEC61000-4-15
Dc %, Dmax % and Time d(t) 0.0 to ± 100.0 % for Dc % and 0.1 % for Dc % and Dmax % and ± 1% for Dc % and Dmax % and
exceeds limits. As described Dmax % and 0.000 to 9.999s 10 ms for Time 20 ms for Time
per I
E
C 6
1
000-3-3
for Time
Unbalance
Volts 0.0 to 5.0 % 0.1 % ± 0.5 %
Current 0.0 to 20 % 0.1 % ± 1 %
Transient capture
Volts ± 6000 Vpk 1 V ± 15 % of cursor reading
± 2.5 % of Vrms
Minimum detect duration 5 µs Sampling rate 200 kS/s
Inrush mode
Arms (A
C+D
C) 0.000 to 20.00 kArms
1
0.00
1 to 1
0 Arms
1
±
1 % of meas
± 5 counts
3
Inrush Duration mm:ss:mmm between 7.5 s to 10 ms ± 20 ms (Fnominal = 50 Hz)
30 m selectable
Fluke 430 Series Three-Phase Power Quality Analyzers Fluke Corporation 5

Fluke 430 Series Specifications

General

Voltage Measurement	Up to 1000 V AC/DC
Power Quality Parameters Measured	Voltage, Current, Harmonics, Flicker, Transients
Harmonics Measurement	Up to 50th harmonic
Display	Color LCD
Memory	Internal memory for data logging
Connectivity	USB
Safety Rating	CAT IV 600 V
Operating Temperature	50°C
Type	Portable
