Fluke 43B Getting Started Guide

Fluke 43B
Getting Started
2
Safety Information: Read First
Read the safety information before using the Fluke 43B.
Specific warning and caution statements, where they apply, will be found
throughout the manual.
A “Warning” identifies conditions and actions that pose hazard(s)
to the user.
A “Caution” identifies conditions and actions that may damage
the Fluke 43B.
The following international symbols are used on the Fluke 43B and in this
manual:
Read the safety information in
the manual
Double Insulation
(Protection Class)
Earth Equipotential inputs,
connected internally
UL 3111 listed
UL1244
UL 1244 listed
Conformité Européenne CSA listed for USA and
Canada
Recycling information Disposal information
Warning
To avoid electrical shock, use only a Fluke power supply, Model
PM8907 (Power Adapter/Battery Charger).

Fluke 43B Specifications

General

Category	Power Quality Analyzer
Interface	RS-232
Volts AC/DC	Yes
Ohms	Yes
Continuity	Yes
Diode Test	Yes
Capacitance	Yes
Harmonics Measurement	Up to 51st harmonic
Display	LCD
Battery Life	Approximately 6 hours
Weight	1.1 kg (2.4 lb)
Data Storage	Yes
Amps AC/DC	0.1 to 1000 A (with clamp)
Power Measurement	W, VA, VAR, PF
Dimensions	50 mm
Current Measurement Range	Via current clamp accessories (not built-in)
