Fluke 715 Instruction Sheet

715 English Instruction Sheet
Page 4
Measuring dc Volts
V
mV
mA
%
mV or V depending
on range
Press so that
INPUT is on
the display
INPUT
Press to toggle
100 mV and
10V ranges
V
mV
it01i.eps
Sourcing dc Volts
V
mV
mA
%
mV or V depending
on range
Press so that
OUTPUT is on
the display
OUTPUT
V
mV
Press to toggle
100 mV and
10V ranges
it02i.eps

Fluke 715 Specifications

General

Battery voltage	9 V
Battery technology	Alkaline
Display type	LCD
Display digits	5 digits
Drop proof up to	1 m
Operating altitude	0 - 3000 m
Operating vibration	2 G
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	0 - 95 %
Holster included	Yes

Weight and Dimensions

Depth	32 mm
Width	87 mm
Height	187 mm
Weight	330 g
