Fluke 80i-410 - Troubleshooting; Calibration Procedure

Table 1. Clamp/Meter Setup Guide
FLUKE MODEL INPUT JACK FUNCTION |
(for red lead)
n a
10,11,12 + 4000 mV ac or de ***
2152837 V Q + 300 mV dc or Vac*
21 Series ||,
23 Series ||
25,27 V Q >+ mV dc or ac
70 V Q >} 300 mV dc or Vac*
TE V Q >+ 300 mV dc or Vac*
73 Series II
SEITE, V Q >+} 300 mV dc or Vac*
75 Series Il,
77 Series Il
78 V Q >} 400 mV dc or Vac*
29,79 Series Il V Q >+ mV dc or Vac
83,85,87,88 V Q >+ mV dc or Vac
8060A,8062A VQ V de or ac**
or
VQs
8020A,8020B, VQ V de or ac**
8021B,8022A, or
8024A,8024B, VQs
8026B |
*Limited to 1A resolution for ac current |
**200mV range for up to 200A, 2V range for up to 1000A
***Limited to 1A resolution for ac or de current
Low Level Measurement
The 80i-410 DC/AC Current Probe is specified to measure currents
of 5A or greater. Currents below 5A can be accurately measured by
looping the input wire through the jaws of the probe so that the sum
of the amp-turns through the jaws is greater than 5A. The actual
current can then be calculated by dividing the meter reading by the
number of turns looped through the jaws.
TROUBLESHOOTING
If the 801-410 DC/AC Current Probe does not perform properly, use
the following steps to help isolate the problem:
1. Inspect the jaw mating surface for cleanliness. If any foreign
material is present, the jaws will not close properly and errors will
result.
2. Inspect the batteries to make sure thay are installed with the
proper polarity. (Refer to the Battery Installation procedure).
Test the batteries. (Refer to the Battery Test procedure.)
Verify thatthe probe leads are connected to the VOLT input of the
meter.
5. Verify that the function selection on the meter is correct, i.e., de
mV for de current or ac mV for ac current.
CALIBRATION PROCEDURE
Required Equipment
The equipment required to calibrate the 80i-410 is listed in Table 2.
Table 2. Required Equipment
INSTRUMENT TYPE RECOMMENDED MODEL
DC/AC Voltage Calibrator Fluke Model 5100B
Transconductance Amplifier Fluke Model 5220A
Digital Multimeter Fluke Model 8050A
Magnet Wire Coil 15 turns of #10 single film coated
copper wire diameter 15* (380
mm) minimum
Small insulated screwdriver N/A
