8508A
Service Manual
5-10
Table 5-3. A5 Bezel (front panel) Assembly
Reference
Designator
Description
Fluke
Part No
Tot Qty Notes
A1 Display PCB Assembly 1988711 1
C1, C2 Capicator, ceramic, 470 pF 10% 2 kV 2397993 2
H1 Screws, 8/32 x 3/8 295105 4
H2 Screw, K25 x 8, POZIPAN SZP, ST 2398217 7
H3 Washer M3, Int-SHAKP SZP 2398239 1
H4 Washer M4, Int-SHAKP SZP 2398256 6
H5 Washer, Terminal 859939 1
H6 Nut, Full, M3, SZP 2398288 1
H7 Nut Terminal 8-32 UNC 850334 12
J1, J2, J3 Terminal, Low Thermal, Red 886382 3
J4, J5 Terminal, Low Thermal, Black 886379 2
J6 Terminal, Low Thermal, Blue 886366 1
L1 Ferrite Core, 8680 nH 2398386 1
MP2 Front Handle 1605343 2
MP3 Display Lens 1607661 1
MP5 Keypad Set 1605272 1
MP4 Front Panel Decal 1607677 1
W1 Cable Assembly, Front Input 2398051 1
