8508A
Service Manual
5-12
Table 5-4. A6 Rear Input Assembly (optional)
Reference
Designator
Description Fluke
Part No
Tot Qty Notes
A1 Rear Input PCA 2399180 1
C1, C2 Capicator CD 470 pF 10% 2 kV 2397993 2
WF1 Fuse 1.6 A 250 V 20 mm 1582072 1
FH Fuse Holder 20 mm Panel Mount 2398399 1
H1 Tie, Cable 3.6 x 142 mm 2398161 1
H2 Washer M4 Int-Shakp SZP 2398256 6
H3 Nut 8-32 UNC Terminal 850334 12
H4 Washer Terminal 859939 6
H5 Washer Terminal Large 613606 6
H6 Washer M3 Int-Shakp SZP 2398239 1
H7 Nut Full M3 SZP 2398288 1
H8 Screw M3 x 6 POSICSK SZP 2398189 2
H9 Tie Cable 2.5 x 115 mm 2398177 3
H10 Tie Holder 2398335 1
H11 Screw M3 x 8 POZIPAN SEMS 2398200 1
H12 Circuit Board, Support 2398364 3
H13 Terminal Insulator 894183 6
H14 Terminal Base 885459 6
J2, J4 Terminal, Low Thermal, Black 886379 2
J1, J3, J5 Terminal, Low Thermal, Red 886382 3
J6 Terminal, Low Thermal, Blue 886366 1
L1 Ferrite 26 x 14 x 11 8680 nF 2398386 1
W1 Cable Assembly Rear Input (8 wires w/ terminals) 2398106 1
