OVEN TRACKER XL2 Thermal Barriers and Heatsinks 31
TB0091 Low-height XL2
Typical applications: 2-piece can manufacture – internal-bake ovens, low-height
mesh-belt ovens, portable system for travelling paint reps.
With Heatsink
Temp °C 100 150 200 250 300
Temp °F 212 302 392 482 572
Duration (mins) 270 150 105 75 48
Dimensions Height Width Length Weight
104 mm 187 mm 291 mm 3.2 kg
4.1 in. 7.4 in. 11.5 in. 7.1 lb
Heatsink 1 × TB9115B
Without Heatsink
Temp °C 100 150 200 250 300
Temp °F 212 302 392 482 572
Duration (mins) 106 66 49 42 35
Dimensions Height Width Length Weight
104 mm 187 mm 291 mm 2.3 kg
4.1 in. 7.4 in. 11.5 in. 5.1 lb
Insert Tray 1 × TB9121
Stainless-steel Thermal Barriers
TB0080 High-temperature XL2 (with Heatsink)
Typical application: high-temperature coating cure, e.g. PTFE, Dacromet.
Temp °C 200 300 400 500 600
Temp °F 392 572 752 932 1,112
Duration (mins) 300 180 120 100 75
Dimensions Height Width Length Weight
150 mm 215 mm 335 mm 7.8 kg
5.9 in. 8.5 in. 13.2 in. 17.2 lb
Heatsink 1 × TB9115B + 1 × TB1001
