CONFIGURATION OF DSX 5000
17
To do:
- with equipment disconnected
- On all the links between each equipments
- Without any voltage on the train (HV or LV)
- be careful to parameterize the device according the cable you want to test (straight or crossed)
Fluke DTX 5000 Cable
Analyser
Fluke DTX 5000
Smart Remote
Figure 6 - Electrical transmission measurements between Car 1 and Car 2
