Fluke IB117L Calibration Information

True-rms Multimeter
Features
5
Features
Table 1 is a list of the features for each Meter.
Table 1. Features
Switch
Position
Measurement Function 110 113 114 115 116 117
OFF The Meter is turned off.    
x
Automatically selects ac or dc volts based on the sensed
input with a low impedance input.

e
AC voltage from 0.06 V to 600 V. 
Frequency from 5 Hz to 100 kHz. 
D
DC voltage from 0.001 V to 600 V. 
l
AC voltage from 6.0 to 600 mV, dc-coupled.
DC voltage from 0.1 to 600 mV.

Ω
Ohms from 0.1 Ω to 40 MΩ. 
Ohms from 0.1 Ω to 60 kΩ. 
s
Continuity beeper turns on at <20 Ω and turns off at
>250 Ω.
   
k CHEK
LoZ low impedance measurement function to
simultaneously test for voltage or continuity.

R Diode Test. Displays OL above 2.0 V. 
S Farads from 1 nF to 9999 μF. 
j
AC current from 0.1 A to 10 A (>10 to 20 A, 30 seconds
on, 10 minutes off). >10.00 A display flashes. >20 A, OL
is displayed. DC-coupled.
Frequency from 45 Hz to 5 kHz.

I
DC current from 0.001 A to 10 A (>10 A to 20 A,
30 seconds on, 10 minutes off). >10.00 A display
flashes. >20 A, OL is displayed.

$
DC current from 0.1 to 600 μA. AC current from 6.0 to
600 μA. DC-coupled.

y
Temperature from -40 °C to 400 °C (-40 °F to 752 °F)
with K-type thermocouple

w
Non-contact sensing of ac voltage. 
Note: All ac functions and Auto-V LoZ are true-rms. AC voltage is ac-coupled. Auto-V LoZ, AC mV and
AC amps are dc-coupled.

Fluke IB117L Specifications

General

Brand	Fluke
Model	IB117L
Category	Multimeter
Language	English
