Fluke III Series User Manual

70/73 English Instruction Sheet
Page 2
Input Jacks
300
mA
10A
COM
FUSED
V
!
Milliamps
Amps
Volts, Ohms, Diode Test
Common Terminal
600V
70
70
hr2f.eps
See Specifications for overload protection.
Pushbutton
Use the pushbutton to either select a fixed range or put the meter
in the Automatic Touch Hold
 mode.
Autorange
The meter defaults to autorange when first turned on.
Manual Range
Manual ranging is available in V ac, V dc, ohms, A ac, and A dc.
Momentary
+
_
V
hr14f.eps
To return to autorange, press R for 1 second or turn the
rotary switch.

Fluke III Series Specifications

General

Model	Fluke III Series
Category	Multimeter
Display	LCD
Diode Test	Yes
DC Voltage Range	0.1 mV to 1000 V
AC Voltage Range	0.1 mV to 750 V
Continuity	Yes
Digits	3.5
