Remote sensin
e drop across the +V and -V wires to the load is substantial, the
volta
e at the load will be less than the pro
rammed value. To prevent the volta
rammed value, the sense wires must also
be connected to the load (remote sensin
allows the power
supply to compensate for volta
e drops in the wires between the power supply
and the load. The sense wires must be connected directly to the load poles.
Note: Lon
sense wires are susceptible to noise pickup. To minimize noise
pickup, twist each pair of sense wires to
around the
sense wires may be necessary in more extreme cases.
- S- V+ V+ S
load
